Product Description
The Rapid-Rate Thermal Cycle Chamber is ideal for test requiring quick changes 15°C/min ramp rate in specimen temperature and 23°C/min ramp rate for air temperature. It covers various applications from JEDEC, IEC standards to screening.
| Model | HYQT-80 | HYQT-150 | HYQT-225 | HYQT-408 | HYQT-1000 |
| Interior WxDxH(cm) | 40x40x50 | 50x50x60 | 50x60x75 | 80x60x85 | 100x100x100 |
| Max.specimen load | 5 kg | 10kg | 12kg | 20kg | 65kg |
| Cooling speed | Optional SL5: 5°C/min ; SL10:10°C/ min; SL15: 15°C / min | ||||
| Temp. range | -70ºC~150°C | ||||
| Temp. fluctuation | ±0. 5°C | ||||
| Temp. uniformity | ≤2. 0°C | ||||
| Temp. deviation | ±2. 0°C | ||||
| Exterior material | Rust proof cool rolled steel plate with surface coating or SUS304 stainless steel | ||||
| Interior material | SUS304 stainless steel | ||||
| Insulation material | Rigid polyurethane Foam | ||||
| Refrigeration mode | Mechanical compression cascade refrigeration | ||||
| Refrigerator | Original imported compressor(TECUMSEH) | ||||
| Refrigerant | R404A/R23 | ||||
| Cooling mode | Water cooled | ||||
| Heather | Quality nickel-chromium alloy heaters | ||||
| Blower | Centrifugal Blower | ||||
| Door window(mm) | Glass incorporating heat generator | ||||
| Temp. sensor | PT100 Platinum resistance sensor | ||||
| Controller | Touch screen programmable controller with English menu | ||||
| Power | 3 phase AC 380V±10% 50Hz | ||||
1. Reasonable structure and fast cooling speed;
2. Wind speed variable frequency regulation;3. Imported refrigeration units and key accessories are all imported from international brands to improve operational reliability:
4. Touch screen, human-machine interface, easy to operate and maintain;
5. There are functions such as studio overheating, compressor overload, overpressure, oil pressure protection, fan overload, phase sequence protection, and delay protection.
6. Suitable for cold resistance testing, adaptability testing under rapid temperature changes or gradual changes in electrical and electronic products and components. Specially used for electricians
purpose
1. Environmental stress screening (ESS) test for electronic products;
2. The external dimensions are determined based on the rate of temperature rise and fall;
3. Water cooled type (water temperature 10-28C, water pressure 0.1-0.3Mpa to ensure cooling performance);
4. It can increase the function of dampness and heat;
5. Optional dry air blowing system;
6. Optional liquid nitrogen function.
1.Q :How to provide after-sales service?
A:If customers need our engineers to come to the site for service, we will send out engineers to provide repair service for you.
2.Q: Can we visit and study in your factory?
A: Welcome to visit and study in our factory, we will show you our R&D and production capacity.
3.Q :Can I install and commission the calibration equipment on site?
A: Yes, we can send technicians and engineers to the customer's site for installation, commissioning and calibration.
4.Q: What are the transportation methods?
A :Air freight, sea freight, railroad transportation, all transportation methods according to the customer's needs.
5.Q : What are the packing methods?
A: Standard export wooden box packaging, solid and firm.
6.Q :How do you calibrate the equipment?
A: We have our own calibration and third-party calibration.
7.Q :What are the payment methods?
A :The payment methods are T/T, CIF, Paypal, L/C, VISA and so on.
8.Q :How long is the warranty period?
A :Warranty is 1 year, lifetime free service.
9.Q :What is the delivery time for your company's products?
A :This depends on the actual product you order, usually at least 30 days.
