Basic Info.
Model NO.
FMOU-22
Movement Way
Combined
Atomization
Gas Atomization
Flow
Parallel Flow
Heating Mode
Dielectric
Material Status
Customisable
Drying Medium
Air
Operation Pressure
Vacuum
Operational Method
Continuous
Model No
Fmou-22
Internal Material
SUS403# Stainless Steel
Weight
About 260kg
Dust-Free Grade
Class100
Temp.Constancy
+/- 0.5 Degree Celsius
Indication Resolution
0.1 Degree Celsius C/1 Degree Celsius
External Material
Baked Enamelled Steel Plate
Insulation
Fiberglass Wool
Appearance
#9003 Light Sand Colour
Temperature Range
+40~1000ºC
Internal Size
W610mm×d610mm×h610mm
Transport Package
Both Can
Specification
Inner size: W610mm× D610mm× H610mm
Trademark
FanQi
Origin
Kunshan, China
Production Capacity
100 Sets/Month
Product Description
| Other Specification | |
| Timer | Adopting electronic timer, the time limit is 0-9999 minutes. |
| Air supply system | Adopting horizontal air supply, special air circuit design to ensure the same air volume up and down and even temperature. |
| Air supply motor | adopts Taiwan-made high temperature resistant oven special long shaft motor, stable performance. |
| Temperature control | Adopt Higashizaki digital thermostat PID algorithm, SSR output. |
| Temperature difference range | <=±1 (6-point empty oven test) |
| Production cycle | (according to the baked product process requirements) |
| Air source | adjustable 6 |
| Exhaust | adjustable 6 |
| Heating time | room temperature heating to 150 ºC about 25 minutes. |
| Inner size | W610mm × D610mm × H610mm (standard machine) |
| Weight | about 260Kg |
| Power supply | AC 380V three-phase 50Hz 18KW |
1. The structure adopts double chamber design, the control box is located on the right side of the machine.
Additional explosion-proof door buckle, equipped with temperature-resistant silicone compression, tight and easy to close and open.
It can prevent accidents from happening. The machine can be used with trolley after landing.
2. Insulation is excellent, six-side heat insulation, heat insulation cotton thickness of not less than 150MM.
The temperature of the exterior of the oven is low, saving energy and environmental protection.
3. Insurance mechanism is superior, over-temperature preventer, motor overload current protection, control line insurance,
electric overload protection, no fuse switch, etc..
4. Mature technology, fast production cycle, perfect logistics channel
5. Comply with international testing standards.
6. Highly customisable.
7. Best after-sales service: one year free parts maintenance.
